Hytrel I-ring crystal gasket 0.35 × 0.70 mm

The in-between height from 0.60 to 0.80 mm

This I-ring crystal gasket is a ring made of Hytrel, a flexible and durable engineering polymer, fitted between the crystal and the bezel or case. It seals the assembly and holds the crystal once it has been pressed in. The 0.70 mm height sits between the two most common values: it is useful when a 0.60 mm gasket is too short for the crystal edge and a 0.80 mm one stands proud.

Available sizes

• 20 diameters, from 14.28 to 31.5 mm, mostly in small and medium sizes (ladies' and classic watches).
• 0.35 mm wall, the standard thickness for I-ring gaskets.
• Single price of €17.90 incl. VAT for every size.

How do you know 0.70 mm is the right height?

The gasket should cover the crystal edge without rising above the bezel. Measure the edge height and the depth of the seat with a caliper; our guide on how to measure a watch gasket explains the method, and the one on how to use a caliper shows how to read the tool. Choose the diameter of the crystal.

Fitting the gasket properly

Never reuse the old gasket: it was compressed during the previous fitting and no longer seals. Degrease the seat, centre the new gasket around the crystal and press gradually, without forcing one side. The full step-by-step is in our guide on how to replace a watch gasket.

Gaskets from the ISO Swiss range.
